Micro Window

Like ordinary optical window sheets, tiny window sheets have two parallel surfaces and are used in most cases to protect sensors and other electronic instruments within the system from environmental conditions, but they are absolutely indispensable and should be adapted to the needs of the overall system.

Specification of Micro Window

Item	Commercial	High Precision
Material	Visible material: BK7 (H-K9L), Float glass, Color glass, etc. UV material: Fused silica, Borosilicate glass, etc. IR material: Sapphire, Ge, Si, CaF2, MgF2, BaF2, LiF, ZnSe, ZnS, etc.
Dimension	1mm~10mm
Diameter Tolerance	±0.1mm	±0.03mm
Angle Tolerance	＜3 arc min	＜10 arc sec
Clear Aperture	>90% of diameter
Surface Quality	MIL60-40	MIL20-10, 10-5
Surface Flatness	λ/4@ 632.8nm	λ/10@ 632.8nm
Chamfer	0.05~0.2mm x 45°

Typical Application Areas

Biomedical and Life Sciences

Medical endoscopes, dental probes, micro-diagnostic chips.
Optical Communication and Optoelectronic Integration

Laser diode (LD) packaging, photodetector (PD) packaging, optical modules.
Laser and Industrial Manufacturing

High-power laser output windows, laser processing head protective windows.
