Home / Custom / Optical Components / Optical Filter / Pixel-Level (Stepwise Gradient) Multi-Channel Filter
Pixel-level (stepwise gradient) multi-channel filters employ a continuous coating process and rely on a multilayer wedge-shaped thin-film structure to achieve spatially continuous variations in optical filtering characteristics. Pixel-level (stepwise gradient) multi-channel filters boast highly integrated spectral separation capabilities, offering irreplaceable advantages in the miniaturization and lightweight design of spectroscopic instruments.
Spectral Range (nm) | 1100-1700 | 1150-1650 (1) | 1150-1650 (2) |
|---|---|---|---|
Single-channel Dimension (μm) | 320 | 240 | 120 |
Number of Spectral Channels | 32 | 32 | 64 |
Channel Half-height Width (nm) | <40 | <15 | <15 |
Filter Size (mm) | 12.80 × 10.24 | 9.60×7.68 | 9.60×7.68 |
| Peak Transmittance (%) | >85% | >85% | >85% |
