Brewster Windows

Brewster windows are uncoated substrates that can be used as polarizers in tandem, or to increase the degree of polarization of partially polarized light. When placed at a precise Brewster angle, it allows light of a specific polarization direction (P-polarized light) to pass through completely without reflection, while reflecting away another portion of the light (S-polarized light).

Contact Us

Inquire Now

Specification of Brewster Windows

Specification & list
Material: UV Fused silica / N-BK7
Surface quality: 10/5 – 20/10
Transmitted wavefront distortion (TWD): λ/10@632.8nm
Brewster angle: 55°32‘ – 55°57’ @633nm
Parallelism: ≤5 arc sec.
Minor Diameters （mm）	Thickness （mm）
6	1
6	2
8	1
8	2
10	2
12.5	2
13	2
16	2
20	2
22	2
25	2

Typical Application Areas

Polarization Optics

1. As a polarizing element in a laser resonant cavity; 2. As a transmission polarizer; 3. As a replacement for thin-film polarizers (high-power applications); 4. Polarization coupling and decoupling.
